26X Opticol Zoom 1080P 500m Laser Network Vehicle/on Board IP PTZ Security Camera


Key Features
1080P 1/2.8" Progressive Scan CMOS;
26X(F5-130mm) optical zoom;
Laser distance:500m
Weatherproof IP66/67;
Synchronization zoom, enabling focus precisely adjusting the light intensity
ONVIF comply;
ideal for mobile surveillance, for vehicle, marine application

Application
Enclosed with aluminum housing and excellent sealing solution, the camera is designed with an ingress protection rating of IP66/67, protecting the internal components from dust, dirt and liquids.
The rugged, mobile mounting options make this camera ideal choice for many mobile surveillance
application:like law enforcement, vehicle surveillance, specialized robot, marine surveillance.

Technical parameters
Model
Model No. SVN-26X500L
Visible Camera
Image Sensor 1/2.8" Progressive Scan CMOS
Effective pixel 1920*1080,2MP
Min. Illumination Color:0.001 Lux @(F1.5,AGC ON); Black:0.0005Lux @(F1.5,AGC ON); IR ON:0Lux
White balance Auto white balance, auto gain, auto exposure
Gain control automatic / manual
Signal to noise ratio ≥55dBG
BLC On / off
Shutter 1/3-1/100,000sec; Support slow shutter
Focus mode automatic / manual
WDR Super wide dynamic, automatic wide dynamic, 0-100 digital adjustment
DNR 3D-DNR
Focal length 5-130mm,26X option Zoom
Day/Night Switch Dual Filter Switching Synchronized Image, Auto, Color, B&W, Timing, Threshold Control, Flip
Pan/Tilt
3D intelligent positioning Support
Pan Range 360° (endless)
Pan Speed 0.05°/s ~ 80°/s
Tilt Range -30° ~ +40° (or -20° ~ +90°)
Tilt Speed 0.05° ~ 60°/s
Scale zoom Support
Preset 255
Cruise scan 6, each of which can add 18 preset points, and the residence time can be set
Power off memory Support
Control support RS485 and network control
Video output support network HD and analog video output
Network
Network interface RJ45 10Base-T/100Base-TX
Image 1920*1080
Frame rate 60fps
Video Compression H.256/H.264
Network Protocol TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,RTP,RTSP,RTCP,NTP,SMTP,SNMP,IPv6
Interface Protocol ONVIF(PROFILE S,PROFILE G)
Video stream Three bit stream
Local storage Support Micro SD/SDHC/SDXC Card (128G) off-network local storage
Security Password protection, multi-user access control
Laser distance 500M
General
Power DC 10V-24V, wide voltage input; Power consumption: 36w
Working temperature -40ºC~65ºC
Working humidity <90%
Ingress Protection IP67, 4000V Lightning protection, surge protection
