7" 5MP 20X 300M IR Distance IP PTZ speed dome Camera
Key Features
5MP 20X Optical Zoom, Auto focus;
Horizontal: 360°, Vertical: 90°, Continuous scanning;
Dual mode connection, 4G/Netwrok or 4G/Wifi Connect;
Automatically correct infrared virtual focus; IR Distance: 300M
Red and blue lamp warning,Alarm voice customization, Two-way voice, Humanoid detection
H. 264 / H.265 video coding, supporting dual bit rate, 0.1m-8mbps;
Support multiple devices to watch one device at the same time
Maximum 128G TF card storage

Technical parameters
Model
Model No. SVN-20XCW75-4G
Camera
Processor HI3516E+SONY335
Image sensor 5MP CMOS Sensor
Resolution 2560*1920
Frame rate 1-25fps
Lens 4.7mm~84.6mm
ZOOM 20X Optical Zoom
APP CamHi
IR distance 300M
Min. Illumination Color:0.1 Lux; Black:0.01Lux;
CMOS performance Support ATW/automatic gain control/automatic BLC, Humanoid detection
Audio
Coding standard AMR/G.711A
Audio input 1 CH built-in - 38dB microphone
Audio output Built-in intercom speaker
TF Card
Storage Maximum support 128G
Recording Timed recording, Alarm recording
Network
Network interface 10Mbps/100Mbps adaptive/RJ45 interface
Network protocol TCP/IP,HTTP,TCP,UDP,SMTP,DHCP,DNS,P2P
Wifi IEEE802.11b/g/n
Wireless 2G: GPRS/EDGE (900/1800), 3G: WCDMA (Band 1/8) / TD-CDMA (Band 34/39), 4G: FDD-LTE (Band 1/3) / TDD-LTE (Band 38/39/40/41)
Alarm
Alarm method Motion Detection
Alarm Output APP push
General
Power DC12V 5A
Power consumption Daytime: 5W, infrared activation at night: 12W
Working temperature -10℃~50℃
Working humidity ≤80%RH
Dimension 420*250*250 mm
Weight 2.8 kg
