4G GPS Systems Portable Microsd Storage Network PTZ Camera
  • Automatic switching of infrared light and white light
  • Supports ONVIF, butt NVR host
  • H.264 video coding, supporting double bit rate, 0.1M-8Mbps
  • Intelligent QOS algorithm automatically adjusts the bit stream and frame rate and adapts the network
  • Wi-Fi connect, Wi-Fi setup, smart home robot
  • Supports 64GB TF card, p2p, iCloud
  • Supports two-way audio, speak face to face
  • Day and night protection, B/W, IR
  • Distance: 50m
  • Security: supports WPA/WPS 2.0 encryption
Model NO.   SVN-W2033SG
Video
Chip Hisilicon
Sensor 2MP CMOS Sensor
Image output 1920*1080
Frame rate 1-30fps
Min.Illumination Color:0.1 Lux,B/W:0.1 Lux
CMOS performance AWB,AGC,BLC
Camera lens 4mm,6mm,8mm,12mm(Optional)
Audio
Coding standard AMR/G.711A
Audio input 1 road built-in -38dB microphone
Audio output Built-in loudspeaker (8 Omega 1W)
TF Card
Storage Maximum support for 64G
Video management
Video mode Timing video, alarm video
Network
Network interface 10Mbps/100Mbps adaptive /RJ45 interface
Network protocol  TCP/IP,HTTP,TCP,UDP,SMTP,DHCP,DNS,P2P
Wireless IEEE802.11b/g/n wireless network
Alarm
Alarm mode Motion detection
Alarm output APP push,E-mail
Other
Power DC12V 2A
Temperature  -10~50ºC
Working humidity ≤80%RH
Power dissipation Day:5W,Infrared start 10Wat night
Gross weight  0.5KG
Packaging size 220*120*115MM

Download PDF
