4CH 720P AHD Mobile Digital Video Recorder
Overview
SVN-S6S41 is a functional Mobile Digital Video Recorder specially designed for vehicle video surveillance and remote monitoring. It has a high-speed processor and embedded operating system, combining with the most advanced H.264 video compression / decompression technology. It supports video recording in 720P, AHD, D1, HD1 and CIF formats. It is easy to use with simple design, multi-functions, single SD cards, superior anti-vibration, flexible installation and high reliability.
Key Features
- Supports 4 channels AHD 720P
- Supports single SD cards for main recording
- 4ch alarm input, 1ch alarm output.
- VGA output
| Model | SVN-MDVR-S6S41 | ||
| Item | Parameter | ||
| OS | Linux | ||
| Video Compression | H.264 | ||
| OSD | date/time, vehicle ID, etc | ||
| GUI | Graphic OSD | Connect to external monitor, use mouse to set parameters | |
|
Video& Recording |
Video Input | 4CH 720P AHD, 4pin Aviation Din, 1.0Vp-p, 75Ω | |
| Video Output | 1CH output+VGA output optional, 1.0Vp-p, 75Ω, 1CH/4CH | ||
| Preview | 1/4ch split display, Support Event alarm, Rear view full display function. | ||
| Resolution | 4CH 720P, and 720P,D1,HD1,CIF optional, | ||
| Image quality | 0-7 levels adjustable (0 is the best) | ||
| Recording Mode | Boot up/Manual/Schedule/Alarm | ||
| Audio | Audio input | 4CH | |
| Audio output | 1CH | ||
| Compression | G.726 , Speed 8KB/s | ||
| Alarm Input | 4CH | ||
| Alarm Output | 1CH | ||
| Serial Port | Optional,1CH RS232 OR 1CH RS485 | ||
| Storage | maximum 256G SD Card | ||
| playback | Video search | by time, mode, etc to search | |
| playback | 4CH playback | ||
| 2X, 4X,8X, 16X forward and backward | |||
| Safety management | user password, admin password, support screen lock. | ||
| Expanding function | TTS | Support TTS voice broadcasting | |
| Serial expansion | Can support advertisement screen, PTZ, oil sensor, etc | ||
| Power and consumption | power management |
wide voltage adaption, support timely open-shut, delay function. |
|
| Input voltage | DC:+8V - +36V | ||
| Output voltage | +12V@1.5A,+5V@1.5A | ||
| Power protection | can automatically save the video when sudden power off to ensure the protection of the file. | ||
| consumption | Working state＜14W, idle＜0.5W | ||
| Working environment | Temperature | -20℃ - +70℃ | |
| Humidity | 20% - 80% | ||
| SD model | Dimension | 150mm*150mm*40mm | |
| Weight | 0.45KG | ||
