4CH 720P AHD wifi 3G/4G GPS Mobile Digital Video Recorder
Overview
SVN-A6S41 is a functional Mobile Digital Video Recorder specially designed for vehicle video surveillance and remote monitoring. It has a high-speed processor and embedded operating system, combining withthe most advanced H.264 video compression / decompression technology, 3G/4G network, GPS positioning technology, as well as WIFI. It supports not only video recording in 720P, 960H, D1, HD1 and CIF formats, but also vehicle travel information recording and wireless data upload. With center software it also achieves alarm linkage central monitoring, remote management and playback analysis. It is easy to use with simple design, multi-functions, Dual SD cards, superior anti-vibration, flexible installation and high reliability.
Key Features
- Supports 4 channels AHD 720P
- Supports dual SD cards for main recording
- Supports GPS for location tracking, optional.
- Supports WIFI for video files download
- Built-in 3G/4G for live view and remote management
- VGA output standard
- Built-in G-sensor
| Model | SVN-A6S41 | ||
| Item | Parameter | ||
| OS | Linux | ||
| Video Compression | H.264 | ||
| OSD | GPS info,date/time, vehicle ID, etc | ||
| GUI | Graphic OSD | Connect to external monitor, use mouse to set parameters | |
|
Video& Recording |
Video Input | 4CH 720P AHD, 4pin Aviation Din, 1.0Vp-p, 75Ω | |
| Video Output | 1CH output+VGA output, 1.0Vp-p, 75Ω, 1CH/4CH | ||
| Preview | 1/4ch split display, Support Event alarm, Rear view full display function. | ||
| Resolution | 720P,960H,D1,HD1,CIF optional, | ||
| Image quality | 1-6 levels adjustable (1 is the best) | ||
| Recording Mode | Boot up/Manual/Schedule/Alarm | ||
| Pre-recording | 15 seconds | ||
| Post-recording | 15-300 seconds | ||
| Audio | Audio input | 4CH | |
| Audio output | 1CH | ||
| Compression | G.726 , Speed 8KB/s | ||
| Alarm Input | 4CH | ||
| Alarm Output | 1CH | ||
| Interface | 1CH RS232 OR 1CH RS485 (can be expansible) | ||
| Intercommunication: support | |||
| Sensor, 4ch inputs, 1ch output | |||
| SIM slot * 1 | |||
| USB2.0 *1 | |||
| Wireless transmission | Optional, 3G/4G(WCDMA,CDMA2000,TDD-LTE,FDD-LTE....) | ||
| Position / G-sensor | GPS optional ,built-in G-sensor,Playback of the route | ||
| Storage | Storage | maximum 2*256G SD Card | |
| playback | Video search | by time, mode, etc to search | |
| playback | 4CH playback | ||
| 2X, 4X,8X, 16X forward and backward | |||
| Safety management | user password, admin password, support screen lock. | ||
| Expanding function | TTS | Support TTS voice broadcasting | |
| Serial expansion | Can support advertisement screen, PTZ, oil sensor, etc | ||
| Power and consumption | power management |
wide voltage adaption, support timely open-shut, delay function. |
|
| Input voltage | DC:+8V - +36V | ||
| Output voltage | +12V@2A | ||
| consumption | Working state＜9W(without cameras), idle＜0.5W. Max. 28W(with camera) | ||
| Working environment | Temperature | -20℃ - +70℃ | |
| Humidity | 8% - 90% | ||
| Physical info | Dimension | 147mm*47mm*42mm | |
| Weight | Approx. 0.45KG | ||
