3" Plastic Humanoid Detection Defog WDR Poe CCTV Network Security H. 265 Onvif Dome IP Camera
Features:
3' Plastic IR Dome IP Camera
IR LED: 14μX12pcs, IR Range: 20M
Video Output: 1 x RJ45 port
Support Onvif, Support Gmail/GOOGLE/QQ/EMAIL
PNP(Plug and Play), support smart phone & tablets
OSD, Motion Detection, Remote View and Control, IR-Cut
Working Temperature: -10ºC~ +60ºC
50PCS Per Carton
Size: 94mm x 69mm
Weight: 320g
Specifications
3' Plastic IR Dome IP Camera
IR LED: 14μX12pcs, IR Range: 20M
Video Output: 1 x RJ45 port
Support Onvif, Support Gmail/GOOGLE/QQ/EMAIL
PNP(Plug and Play), support smart phone & tablets
OSD, Motion Detection, Remote View and Control, IR-Cut
Working Temperature: -10ºC~ +60ºC
50PCS Per Carton
Size: 94mm x 69mm
Weight: 320g
Specifications
| Model ID | SVN-WIOB20LS | SVN-WIOB20TS | SVN-WIOB30CS | SVN-WIOB40PS | SVN-WIOB50XS |
| Description | 3'' Plastic IR Dome IP Camera,IR LED: 14μX12pcs, IR Range: 20M | ||||
| TV System | NTSC / PAL | ||||
| Video Output | 1 x RJ45 port | ||||
| Chipset Solution |
1/2.8" 2.0 MP CMOS Low illumination SC307E + XM530 |
1/2.8" 2.0 MP CMOS Starlight Low illumination SONY IMX307 + HI3516EV200 |
1/2.7" 3.0 MP CMOS Low illumination SC4239 + Hi3516EV200 |
1/2.7" 4.0 MP CMOS Low illumination SC5239 + XM530 |
1/3" 5.0 MP CMOS Low illumination SONY IMX335 + HI3516EV300 |
| Resolution | 1080P@25fps, 720P@25fps | 1080P@25fps, 720P@25fps | 3MP@20fps, 1080P@25fps | 4MP@20fps, 3MP/1080P@25fps | 5MP@20fps, 3MP/1080P@25fps |
| Effective Pixels | 1920(H)×1080(V) | 1920(H)×1080(V) | 2048(H)×1536(V) | 2688(H)×1520(V) | 2560(H)×1920(V) |
| Minimum Illumination | 0.001Lux | ||||
| Lens | 3.6mm Board Lens/2.8mm ( Optional ) | ||||
| Sync,System | Internal Synchronization | ||||
| Network | 1 RJ45 Ethernet interface, 10/100M adaptation | ||||
| Video Compression | H.265 compression | ||||
| Protocol | Support Gmail/GOOGLE/QQ/EMAIL | ||||
| Onvif | Support Onvif | ||||
| AI WDR | YES | NO | NO | YES | YES |
| AI Defog | YES | NO | NO | YES | YES |
| AI humanoid Detection | YES | NO | NO | YES | YES |
| S/N Ratio | ≥ 58dB | ||||
| POE | Optional(Externial POE) | ||||
| WIFI | NO | ||||
| Power Source | DC 12V/2A | ||||
| Consumption | <5W | ||||
| Operating Enviroment | -10ºC~60ºC / 10% ~ 95%RH | ||||
| Working Humidity | ≤90% | ||||
| Size(mm) | 94mm x 69mm | ||||
| Weight(kg) | 0.32 KG | ||||
