46X Opticol Zoom 1080P 1000m Laser IP67 Marine PTZ Camera with Gyro Stabilisation

Key Features

  1. Starlight optical Camera with 1/2.8 Cmos sensor, 322mm lens, 46x Zoom;
  2. Optional laser illuminator up to 1000meter;
  3. 360° omnidirectional high-speed PTZ; ±90° Tilt range;
  4. Built-in heater/fan, allows the withstand the harshest climates;
  5. Gyro Stabilisation, 2 axis;
  6. Marine rated design;
  7. Onvif Support;
Coastal Surveillance and Reconnaissance, Harbor and Offshore Platform Security, Maritime Traffic monitoring, Oil Spill and Water Pollution Detection, Search and Rescue, Coast Guard and Patrol Boats, Critical Infrastructure Protection.

Product Parameters

Model No. SVN-246X77L1
Image Sensor 1/2.8" Progressive Scan CMOS, 1080P
Effective pixel 1920(H) x 1080(V), 2 Megapixels;
Min. Illumination Color: 0.001Lux@F1.8; B/W:0.0005Lux@F1.8
Focal Length 7mm~322mm
Optical Zoom Optical Zoom 46x
Aperture Range F1.8-F6.5
Field of View 42.0-1°(Wide-Tele)
Working Distance 100-1500mm(Wide-Tele)
Zoom Speed Approximately 5s(optical lens, wide-tele)
Pan Range 360° (endless)
Pan Speed 0.05°/s ~ 80°/s
Tilt Range -90° ~ +90° (auto reverse)
Tilt Speed 0.1° ~ 20°/s
Preset 255
Patrol 6 patrols, up to 18 presets per patrol
Pattern 4 , with the total recording time not less than 10 mins
Power loss recovery Support
Laser distance 1000m
Laser intensity Automatically adjusted, depending on the zoom ratio
Compression H.265/H.264 / MJPEG
Streaming 3 Streams
BLC BLC / HLC / WDR(120dB)
White Balance Auto,ATW,Indoor,Outdoor,Manual
Gain Control Auto / Manual
Ethernet RJ-45 (10/100Base-T)
Interoperability ONVIF, PSIA, CGI
Web Viewer IE10/Google/Firefox/Safari...
Power AC 24V, 72W(Max)
Working temperature -40ºC~60ºC
Humidity 90% or less
Protection level Ip67, TVS 4000V Lightning protection, surge protection
Mount option Wall Mounting, Ceiling Mounting
Weight 9.5 kg
